Ο Kondo Audio Note Melius ειναι δικαναλος τελικος ενισχυτης 2x 32 wrms και υλοποιειται με λυχνιες EL34.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα ανταλλαγων, δοσεων.

Push-pull circuit further refined from Overture: The first stage and driver stage are direct coupled, and a new generation pure silver foil capacitors with vibration suppression are used for coupling with the output stage. Moreover, the low impedance design of the whole circuit is aimed the direct sound performance. The output stage continue to employ CCB (constant current bias circuit). The music signal is prevented from flowing into the bias adjustment VR, enabling pure signal transmission.

Optimized wiring: Internal wirings are skillfully arranged so that shortest paths and best performance are obtained. SSW (Silk Silver Wire) are used for internal wirings. Ls-41 are used for paths in which shielding are needed.

Super High Quality Parts: All parts were carefully chosen after massive hours of listening tests. Silver foil capacitors, silver lead resistors, SSW silk silver wires, Ls-41 shield cable, Audio Note custom made output transformers and power transformer. All CR part are carefully selected and arranged.

Specifications

• Product EL34 Push-Pull stereo power amplifier
• Model MELIUS
• Rated Power 32W + 32W @1kHz, 1.5% THD
• Frequency Response 10Hz ? 70kHz (+0dB -3dB @ 1W)
• Input / Impedance 2pairs (RCA, XLR, unbalanced) / 70kΩ
• Output    4Ω, 8Ω
• Noise lower than 0.5mV
• Vacuum tube EL34 x4, 12BH7 x2, 6072 x2
• Power consumption 180W
• Dimension 438mm(W) 204mm(H) 369mm(D) (excluding protrusions)
• Weight 26kg
