Ο Luxsin X8 ειναι ενισχυτης ακουστικων και δευτερευοντως προενισχυτης με usb dac. Διαθετει 8 x CS43198 σε true dual-mono αρχιτεκτονικη, AI-assisted PEQ tuning, αυτοματη αναγνωριση/προσαρμογη ωμικης αντιστασης ακουστικων, ρυθμιζομενο crossfeed και soundstage.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

The Luxsin X8 is built around eight Cirrus Logic CS43198 DAC chips arranged in a true dual-mono parallel architecture, with four DACs operating in parallel per channel. The left and right channels are fully isolated in power supply, circuit layout and signal path, reducing crosstalk and interference while improving dynamic range, signal-to-noise ratio and low-level detail retrieval. A dedicated high-speed buffering and clock-domain distribution stage keeps all DACs precisely synchronized for stable imaging and accurate spatial presentation.

Its digital platform is based on Luxsin’s custom Digital Audio Core, combining a dual-core HiFi-5 DSP with ARM architecture for advanced real-time audio processing. This platform supports AI-assisted PEQ tuning, allowing the user to tailor the sound profile through app or web control with high precision, while also enabling advanced DSP functions and future firmware-based feature expansion. The DAC section is additionally protected by dedicated shielding covers to reduce interference and help maintain thermal stability during long-term high-resolution playback.

The headphone amplification stage uses multiple OPA1612 op-amps together with TPA6120A2 high-current drivers to deliver high output power with low distortion and strong linearity. The X8 also features automatic headphone impedance detection across all headphone outputs, with smart gain matching that operates outside the main signal path so it does not affect audio purity. A fully separated, ultra-low-noise linear power supply with independent digital and analog sections further improves background silence, stability and overall sonic cleanliness.

Specifications

• General
  • Model: Luxsin X8
  • Type: DAC / Headphone Amplifier / Preamplifier
  • Display: 4" LCD touchscreen (480 x 960)
  • Control Methods: Touchscreen, Mobile App (Android/iOS), Web Browser, Optional IR Remote
  • Wi-Fi: 2.4 GHz / 5 GHz
  • Bluetooth: Qualcomm SXW5125, Bluetooth 5.1
  • Rated Power Consumption: 25 W
• DAC & Digital Processing
  • DAC Chips: 8 × Cirrus Logic CS43198
  • Architecture: True dual-mono, 4 DACs per channel
  • Digital Processing Core: Dual-core HiFi-5 DSP + ARM architecture
  • USB-B / USB-C Input: PCM up to 768 kHz / 32-bit, Native DSD512
  • IIS Input: PCM up to 768 kHz / 32-bit, Native DSD512
  • Coaxial / Optical Input: PCM up to 192 kHz / 24-bit
  • USB-A Input: For local upgrade
• Inputs / Outputs
  • Digital Inputs: USB-A, USB-B, USB-C, IIS, Coaxial, Optical
  • Trigger: 12V Trigger In / Out via 3.5 mm connector
  • Analog Outputs: RCA, XLR
  • Headphone Outputs: 6.35 mm unbalanced, 4.4 mm balanced, 4-pin XLR balanced
• Headphone Amplifier Performance
  • Balanced Output Power (4.4 mm / XLR4, High Gain): L+R ≥ 4840 mW + 4840 mW @16Ω (THD+N <1%)
  • Unbalanced Output Power (6.35 mm, High Gain): L+R ≥ 2900 mW + 2900 mW @16Ω (THD+N <1%)
  • Output Impedance: <1Ω
  • Balanced THD+N: <-117 dB (1 kHz / 0 dB @32Ω)
  • Balanced SNR: ≥123 dB
  • Balanced Crosstalk: ≥119 dB (1 kHz @32Ω)
  • Unbalanced THD+N: <-115 dB (1 kHz / 0 dB @32Ω)
  • Unbalanced SNR: ≥121 dB
• Analog Output Performance
  • XLR Output SNR: ≥129.5 dB
  • XLR THD+N: <-121.8 dB (unweighted)
  • XLR Crosstalk: ≥133 dB (1 kHz @200 kΩ)
  • XLR Noise Floor: <1.1 uVrms
  • XLR Output Level: 4.2 Vrms (1 kHz @200 kΩ)
  • RCA Output SNR: ≥124.5 dB
  • RCA THD+N: <-120 dB (unweighted)
  • RCA Crosstalk: ≥125 dB (1 kHz @100 kΩ)
  • RCA Noise Floor: <1.3 uVrms
  • RCA Output Level: 2.1 Vrms (1 kHz @100 kΩ)
• Power Supply
  • Type: Ultra-low-noise, voltage-adjustable linear power supply
  • Design: Fully separated digital and analog power sections
  • Input Power: AC 100-120V / 220-240V, 50/60 Hz
• Physical
  • Dimensions: 236 × 236.8 × 64 mm
  • Weight: 2.75 kg
• Included Accessories
  • Power Cable ×1
  • USB-B Cable ×1
  • 3.5 mm to 6.35 mm Adapter ×1
