Το FiiO BTR17 είναι φορητό Bluetooth DAC και ενισχυτής ακουστικών υψηλής απόδοσης, με εξόδους 3.5mm single-ended και 4.4mm balanced, κατάλληλος για χρήση με υπολογιστές, smartphones και tablets, τόσο ασύρματα όσο και ενσύρματα, με δυνατότητα λειτουργίας και σε Desktop mode.

Εγγύηση Αντιπροσωπείας. Δυνατότητα δόσεων.

The FiiO BTR17 is a flagship-grade portable Bluetooth DAC and headphone amplifier that brings desktop-class performance into a compact, pocketable device. At its core are dual ESS ES9069Q DAC chips working in fully balanced configuration, combined with the Qualcomm QCC5181 Bluetooth 5.4 chipset to support modern hi-res codecs including LDAC, aptX HD, aptX Adaptive, and aptX Lossless, delivering near lossless wireless audio quality.

For wired use, the BTR17 is equipped with a 3rd-generation 16-core XMOS XU316 USB controller that enables ultra-stable low-latency transmission and supports up to 768 kHz / 32-bit PCM, native DSD512 and full MQA decoding in USB DAC mode. Driver-free UAC1.0 mode ensures broad compatibility with gaming consoles and other devices.

The analog stage is based around THX AAA-78+ amplification, offering powerful, low-distortion output with excellent control and dynamics. In Desktop mode with external power, the balanced 4.4 mm output can deliver up to 650 mW + 650 mW into 32 Ω, while the 3.5 mm single-ended output offers up to 280 mW + 280 mW into 32 Ω, making the BTR17 suitable for both sensitive IEMs and demanding full-size headphones.

A 1.3-inch 240 × 240 colour IPS display provides clear visual feedback of volume, gain, codec, sampling rate, USB mode and battery status, while the physical volume wheel and side buttons allow intuitive control on the go. The device supports a 10-band PEQ via the FiiO Control app and PEQ web interface, letting users tailor the sound precisely to their preferences.

With its aluminium alloy chassis, leather-style rear panel, multi-mode (Phone / PC / Desktop) switch and robust power management, the BTR17 is designed to integrate seamlessly into portable, desktop and in-car setups. It is a truly versatile Bluetooth DAC/AMP for audiophiles who want maximum flexibility, power and refinement from a single compact unit.

Specifications

• General Specifications
  • Name/Model: BTR17
  • DAC: ES9069Q × 2 (dual-mono balanced architecture)
  • USB controller: XMOS XU316 16-core
  • Bluetooth chipset: Qualcomm QCC5181
  • Bluetooth version: 5.4
  • Supported Bluetooth codecs: SBC, AAC, aptX, aptX HD, aptX Adaptive, aptX Lossless, LDAC
  • Display: 1.3-inch colour IPS, 240 × 240
  • Housing: Aluminium alloy body with leather-style back (varies by colour version)
  • Dimensions: about 16.3 × 41.2 × 86.6 mm
  • Weight: about 73.4 g
  • Gain: L / H
  • Operating modes (3-position switch): PHONE / PC / DESKTOP
  • USB DAC driver-free mode: UAC1.0 supported (e.g. game consoles)
  • MQA: Full decoding supported (USB DAC)
• Buttons and Controls
  • Volume wheel (rotary encoder with press function)
  • Multifunction buttons:
    • Play / Pause / Call control
    • Track control (Next / Previous)
    • Menu / Back (depending on firmware layout)
  • Three-position mode switch: PHONE / PC / DESKTOP
  • Power / Screen control (short/long press behaviour)
• Ports and Connectivity
  • Headphone outputs:
    • 3.5 mm single-ended headphone out
    • 4.4 mm balanced headphone out
  • USB port:
    • USB Type-C (data & power; used for USB DAC and charging)
  • Wireless:
    • Bluetooth 5.4 with multipoint device pairing (depending on firmware)
    • Supports high-resolution codecs including LDAC and aptX Lossless
• USB DAC / Digital Audio Support
  • USB DAC (XMOS XU316):
    • PCM: up to 768 kHz / 32-bit
    • DSD: up to DSD512 (Native)
    • MQA: Full decoding supported
  • PEQ:
    • 10-band high-precision PEQ
    • Supports adjustment up to 192 kHz
    • Presets and user profiles via FiiO Control app / PEQ web interface
• Audio Parameters – Headphone Output 3.5 mm (UAC decoding, Desktop mode, High gain)
  • Output power:
    • L + R ≥ 330 mW + 330 mW (16 Ω, THD+N < 1%)
    • L + R ≥ 280 mW + 280 mW (32 Ω, THD+N < 1%)
    • L + R ≥ 30 mW + 30 mW (300 Ω, THD+N < 1%)
  • Output impedance: < 1 Ω
  • Crosstalk: ≥ 78 dB
  • Peak output voltage: 9.8 Vp-p
  • SNR: ≥ 124 dB (A-weighted)
  • THD+N: < 0.0004% (1 kHz / –2 dB @ 32 Ω)
  • Frequency response:
    • 20 Hz – 80 kHz: attenuation < 2.8 dB
    • 20 Hz – 20 kHz: attenuation < 0.07 dB
  • Noise floor: < 2.2 μV (A-weighted)
• Audio Parameters – Headphone Output 4.4 mm Balanced (UAC decoding, Desktop mode, High gain)
  • Output power:
    • L + R ≥ 480 mW + 480 mW (16 Ω, THD+N < 1%)
    • L + R ≥ 650 mW + 650 mW (32 Ω, THD+N < 1%)
    • L + R ≥ 125 mW + 125 mW (300 Ω, THD+N < 1%)
  • Output impedance: < 1.5 Ω
  • Crosstalk: ≥ 120 dB
  • Peak output voltage: 17.5 Vp-p
  • SNR: ≥ 126 dB (A-weighted)
  • THD+N: < 0.00035% (1 kHz / –10 dB @ 32 Ω)
  • Frequency response:
    • 20 Hz – 80 kHz: attenuation < 3 dB
    • 20 Hz – 20 kHz: attenuation < 0.1 dB
  • Noise floor: < 2.2 μV (A-weighted)
• Audio Parameters – Headphone Output 3.5 mm (UAC decoding, Non-Desktop mode, High gain)
  • Output power:
    • L + R ≥ 130 mW + 130 mW (16 Ω, THD+N < 1%)
    • L + R ≥ 140 mW + 140 mW (32 Ω, THD+N < 1%)
    • L + R ≥ 20 mW + 20 mW (300 Ω, THD+N < 1%)
  • Output impedance: < 1 Ω
  • Crosstalk: ≥ 78 dB
  • Peak output voltage: 6.5 Vp-p
  • SNR: ≥ 120 dB (A-weighted)
  • THD+N: < 0.0022% (1 kHz / –12 dB @ 32 Ω)
  • Frequency response:
    • 20 Hz – 80 kHz: attenuation < 3 dB
    • 20 Hz – 20 kHz: attenuation < 0.1 dB
  • Noise floor: < 2.1 μV (A-weighted)
• Audio Parameters – Headphone Output 4.4 mm Balanced (UAC decoding, Non-Desktop mode, High gain)
  • Output power:
    • L + R ≥ 180 mW + 180 mW (16 Ω, THD+N < 1%)
    • L + R ≥ 300 mW + 300 mW (32 Ω, THD+N < 1%)
    • L + R ≥ 35 mW + 35 mW (300 Ω, THD+N < 1%)
  • Output impedance: < 1.5 Ω
  • Crosstalk: ≥ 105 dB
  • Peak output voltage: 9.3 Vp-p
  • SNR: ≥ 122 dB (A-weighted)
  • THD+N: < 0.0008% (1 kHz / –4 dB @ 32 Ω)
  • Frequency response:
    • 20 Hz – 80 kHz: attenuation < 3 dB
    • 20 Hz – 20 kHz: attenuation < 0.1 dB
  • Noise floor: < 2.3 μV (A-weighted)
• Power and Battery
  • Power supply (charging): DC 5 V ≥ 1 A via USB-C
  • Battery life: about 8 h (LDAC, typical conditions)
  • Charging time: ≤ 2 h
  • Desktop mode: uses external power for maximum output and reduced load on USB host
