Τα Indiana Line Lira 3 ειναι ζευγος ηχειων 2 δρομων, με 1x 7" woofer και 1x 1.1" al-mag tweeter. Διαχειριση ισχυος 30 εως 160 watts.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Symbiotic Drive concept
Lira 3 is a two-way design that fuses Indiana Line’s decades of know-how with an innovative mindset. It is conceived around our unique Symbiotic Drive approach, in which the drive units, cabinet and crossover network are developed from the ground up as a single, coherent electroacoustic system. Carefully selected materials – woven polypropylene (Curv), an aluminum-magnesium alloy (Al-Mg), MDF and bamboo – contribute directly to the elevated sound quality. The clean, minimalist look is accentuated by a trim ring that neatly conceals the woofer’s mounting hardware, creating a smooth, uninterrupted baffle.

Advanced tweeter transducer
The Lira 3’s tweeter is a proprietary design with a 28-mm aluminum-magnesium (Al-Mg) dome. With over 20% more radiating area than standard dome tweeters, it achieves higher sensitivity. A narrow surround minimizes moving mass, while the ultra-thin 50-micron dome ensures exceptionally pure treble. The motor system is a refined assembly featuring a neodymium magnet, a copper shorting ring and advanced cooling.

Curv-diaphragm woofer
Low and mid frequencies are handled by a new 7-inch long-throw driver with a Curv diaphragm capable of impressive bass output. Its sophisticated motor combines a robust ferrite magnet with three shorting rings (two aluminum and one copper) to control inductance and minimize distortion. Second-generation Dual-Wave suspension enables a wide operating bandwidth and suppresses intermodulation distortion at large excursions, while working in perfect harmony with the Curv diaphragm to control midrange resonances.

A meticulously engineered crossover
The advanced crossover, mounted behind the loudspeaker terminals, employs high-grade components including air-core inductors and polypropylene capacitors. The dedicated LC-Trap filter maximize each driver’s usable range. In keeping with the Symbiotic Drive philosophy, the network’s gentle slopes ensure exemplary phase coherence, creating the impression of a single wideband source.

Specifications

• Design & Construction
  • Holistic Symbiotic Drive design
  • 2-way stand-mount construction
  • MDF cabinet with 21 mm thick front baffle
  • Rear-tilted baffle with non-parallel side walls
  • Internal bracing with black bamboo panels
  • Front-firing bass-reflex system
  • Matte multilayer lacquer finish (PE + PU)
  • Magnetically attached grille
• Drive Units
  • Tweeter: 28 mm aluminum–magnesium (Al-Mg) dome with 3D-Guide waveguide
  • Mid-Bass Driver: 7″ Curv diaphragm with triple shorting rings
  • Woofer Suspension: Second-generation Dual-Wave
• Performance
  • Frequency Response: 40 Hz – 30 kHz
  • Sensitivity 88 db
  • Recommended Amplifier Power: 30 – 160 W
• Cabinet & Dimensions
  • Dimensions (H × W × D): 375 × 205 × 336 mm
  • Weight: 8 kg
