Η Audio-Technica AT-33EV ειναι κεφαλη κινητου πηνιου (Dual Moving Coil), χαμηλης εξοδου, με ελλειπτικη βελονα. Εξοδος 0.30mV

The new half-inch standard mount .3 x .7 mil elliptical AT33EV cartridge features a tapered duralumin cantilever. Dual Moving Coil cartridge design increases channel separation and extends the frequency response range delivering extraordinary audio quality. Internally constructed with neodymium magnet for enhanced magnetic energy and PCOCC wire for pure audio transmission.

Specifications

• Frequency Response     15 - 50,000Hz
• Channel Separation     30dB (1kHz)
• Vertical Tracking Angle     23°
• Vertical Tracking Force     1.8 to 2.2 g (standard 2.0 g)
• Stylus Construction     Nude Square Shank
• Recommended Load Impedance     More than 100Ω (when head amp connected)
• Coil Impedance     10Ω (1kHz)
• DC Resistance     10Ω
• Coil Inductance     22µH (1kHz)
• Output Voltage     0.3mV (1kHz and 3.54cm/sec.)
• Output Channel Balance     0.5dB (1kHz)
• Stylus Shape     Elliptical
• Cantilever     Duralumin
• Static Compliance     40×10-6cm/dyne
• Dynamic Compliance     10×10-6cm/dyne (100Hz)
• Mounting     1/2" Centers
• Dimensions     H16×W16.6×D26.5mm
• Accessories Included     Non-magnetic screwdriver × 1, Washer × 2, Protector × 1, Cartridge installation screws 13 mm × 2 and 19 mm × 2, Nut × 2, Brush × 1, PCOCC lead set × 1
• Body Material     Aluminium/Synthetic Resin
• Stylus Curvature Radius     0.3 x 0.7 mil
• Terminal Pins     Brass
• Type     Dual Moving Coil
• Weight     6.9g
