O Tsakiridis Devices Hermes ειναι τηλεχειριζομενος ολοκληρωμενος ενισχυτης ταξης ΑB. 2x25 wrms με λυχνιες EL84.  Εισοδοι: 3x Line.

Δυνατοτητα ακροασης, ανταλλαγης και δοσεων.

Hermes uses the EL84 tube which is widely acknowledged for its full and high quality sound. Arranged in a double push-pull configuration to obtain enough power to drive a wide range of loudspeakers. The self biasing circuit is a nice convenience for the user.
Gold plated RCA connectors are implemented for the signal inputs/output and high quality binding posts for the loudspeakers. For the volume control the classic blue Alps is used.
An elegant remote control in aluminum case offers you control over all the functions of Hermes integrated amplifier. Volume control, input selection and mute.

Carefully selected values and types of the electronic components contribute to the reliable circuits operation and the high sound quality of the amplifier. The meticulous PCB design ensures excellent behavior in SNR, distortion and channel separation.
Inner signal wiring with high quality shielded signal cable. Power wiring uses high quality copper cables of more-than-needed AWG gauge, to achieve low impedance power transfer. All power cables are twisted in pairs to minimize the electromagnetic interference.

The handmade multilayer output transformers allow the amplifier to reveal the sound stage and all the music details through the entire audio spectrum.
Made by us and tested thoroughly for quality and reliability.
The same applies to the power transformer.
The positioning of the transformers is such that minimizes the magnetic coupling between power and output transformers.

Features

• Inputs: 3 line inputs
• Input selection: High grade signal relays
• Input/Output connectors: RCA gold plated
• Speaker connectors: Ultimax
• Remote control: Yes
• Volume control: Blue Alps
• Power supply capacitors: United Chemicon 105oC
• Signal capacitors: Non inductive polypropylene film capacitors
• Power resistors: Carbon film 5% tolerance
• Low power resistors: Metal film 1% tolerance
• Power transformer: Handmade 250W
• Output transformer: Handmade 8 layer windings
• Driving stage tubes: 1x12AU7 and 2x12AT7
• Power tubes: 8xEL84

Specifications

• Output Power: 2x25W
• Input impedance: 47 kOhm
• Output impedance: 6 Ohm
• Input sensitivity: 350mV
• Signal to Noise Ratio (SNR): 84db
• Channel separation: 67db
• Rise time: 6us @ 10kHz
• Harmonic distortion: 10W @ 1kHz 0.48%
• Frequency response: -3db 10Hz-47000Hz
• Power supply energy: 80Joule
• Power consumption: 90W
• Weight: 14kgr
• Dimensions (WxDxH): 29x44x22 cm
