Η JBL Bar 1300MK2 ειναι ηχομπαρα Dolby Atmos 11.1.4, περιλαμβανει ασυρματο ενεργο subwoofer 10" και 2 αποσπωμενα surround ηχεια. Υλοποιειται με 19+1 μεγαφωνα και ψηφιακους ενισχυτες συνολικης ισχυος 950 watts με THD 1%.
Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.
11.1.4 channel soundbar system with detachable surround speakers, MultiBeam 3.0™, Dolby Atmos® and DTS:X®
Experience the pinnacle of 3D surround sound with breathtaking height channels. Six up-firing speakers in the soundbar and the wireless rear speakers deliver true Dolby Atmos® sound. No extra wires. No power connections. Just lift the detachable surround speakers off the soundbar—you can do it with just one hand—and place them behind where you're sitting to create a true surround-sound experience. It's that simple. Whether you're binge-watching your new favorite show or hosting a movie night, the speakers' long-lasting batteries mean you'll enjoy immersive, cinematic surround sound for hours. And when you're done, just place the speakers back on the bar to recharge overnight.
Specifications
- Model: BAR 1300MK2 (soundbar) / BAR 1300MK2 SURROUND (detachable speaker) / BAR 1300MK2 SUB (subwoofer)
- Sound System: 11.1.4 channel
- Power Supply: 100–240 V AC, 50/60 Hz
- Total Speaker Power Output (Max @ THD 1%): 2470 W
- Soundbar Output Power (Max @ THD 1%): 950 W
- Surround Speaker Output Power (Max @ THD 1%): 2 × 160 W
- Subwoofer Output Power (Max @ THD 1%): 1200 W
- Soundbar Transducer: 8 × (50 × 75 mm) racetrack drivers, 7 × 1" (25 mm) tweeters, 4 × 3" (75 mm) up-firing full-range drivers
- Surround Speaker Transducer: 2 × (50 × 90 mm) racetrack drivers, 1 × 2" (50 mm) full-range driver, 1 × 3" (75 mm) up-firing full-range driver
- Subwoofer Transducer: 2 × 8" (200 mm)
- Networked Standby Power: < 2 W
- Operating Temperature: 0°C – 45°C
- Lithium Battery: 7.2 V, 4722 mAh
- Detachable Surround Speaker Playtime: up to 10 hours
- Frequency Response: 33 Hz – 20 kHz (-6 dB)
- Audio Inputs: Optical, Bluetooth, USB
USB playback only on US versions; others support Service only
- Dimensions
- Total Soundbar (W × H × D): 1404 × 58 × 136 mm
- Main Soundbar (W × H × D): 1030 × 58 × 136 mm
- Detachable Surround (each): 202 × 58 × 136 mm
- Subwoofer (W × H × D): 315 × 277 × 275 mm
- Weight
- Soundbar: 5.93 kg
- Detachable Surround (each): 1.3 kg
- Subwoofer: 12 kg
- Packaging Dimensions (W × H × D): 1124 × 381 × 452 mm
- Packaging Weight
- EMEA/UK: 28.6 kg
- JP/IN/CN: 24.3 kg
- AU/NZ: 28.8 kg
- APAC Others: 24.5 kg
- USB Port: Type A
- USB Rating: 5 V DC, 0.5 A
- Supported File Formats: MP3
- MP3 Codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
- MP3 Sampling Rate: 16–48 kHz
- MP3 Bitrate: 80–320 kbps
- Bluetooth Version:
Main Bar: v5.3
Detachable Surround: v5.4
- Bluetooth Profile:
Main Bar: A2DP v1.3, AVRCP v1.5
Detachable Surround: A2DP / AVRCP (version indicated in spec)
- Bluetooth Transmitter Frequency Range: 2400–2483.5 MHz
- Bluetooth Transmitter Power: < 15 dBm (EIRP)
- Wi-Fi Network: IEEE 802.11 a/b/g/n/ac/ax (2.4 GHz / 5 GHz)
- 2.4G Wi-Fi Transmitter Frequency Range: 2412–2472 MHz
- 2.4G Wi-Fi Transmitter Power: < 20 dBm (EIRP)
- 5G Wi-Fi Transmitter Frequency Range: 5.15–5.35 GHz, 5.470–5.725 GHz, 5.725–5.825 GHz
- 5G Wi-Fi Transmitter Power:
- 5.15–5.25 GHz: < 23 dBm
- 5.25–5.35 GHz & 5.470–5.725 GHz: < 20 dBm
- 5.725–5.825 GHz: < 14 dBm
- 5G Wireless Transmitter Power:
- 5.15–5.25 GHz: < 23 dBm
- 5.25–5.35 GHz & 5.470–5.725 GHz: < 20 dBm
- 5.725–5.825 GHz: < 14 dBm
- Note: 5.6–5.64 GHz band disabled in AU/NZ
What's in the Box
- Main soundbar × 1
- Detachable wireless surround speakers × 2
- Wireless subwoofer × 1
- Remote control with 2 batteries
- Power cords (up to 6 pcs depending on region SKUs)
- HDMI cable × 1
- L-shape wall-mount brackets for main bar × 2
- U-shape wall-mount brackets for surround speakers × 2
- Bracket kit with screws
- Side caps × 4
- Quick start guide
- Safety instruction and warranty card
- Wall-mount template
