Το Musical Fidelity M3x DAC ειναι usb dsd dac. Αποκωδικοποιει αρχεια PCM 24-32bit/192kHz, DSD 256/kHz.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Features

• PCM1795 DAC with SRC4392 Upsampling Chip
• 2 digital PCM filters & 2 analogue DSD filters
• PCM inputs upsampled to 192kHz
• USB: up to 32bit/192kHz
• USB: DSD 256 (stereo DoP and native)
• SPDIF: up to 24bit/192kHHz
• 1x USB, 2x coaxial, 2x optical inputs
• 1x RCA, 1x balanced XLR output
• Affordable entry into high-end DACs
• Very low noise
• Extremely low distortion
• Outstanding linearity
• Outstanding channel separation
• Super Silent Power Transformer
• Balanced and RCA output
• Heavy aluminium frontplate with steel chassis
• Minimal electromagnetic interference from power supply to DAC circuitry
• Roon Tested (*pending)
• Made in the EU

Specifications

• DAC
  • DAC Chip: PCM1795
  • Sample rate converter: SRC4392
  • Total correlated jitter: < 48 picoseconds peak to peak
  • Linearity: < 0,2dB down to -100dB
  • Frequency response: -0,2dB at 20Hz, 0,1dB at 20kHz; 1,5dB at 70kHz
  • Channel separation: < -115dB 10kHz @ 0dBFS
  • Signal to noise: >107dB “A”- wtd 1kHz @ 0dBFS
  • Total harmonic distortion: < 0,005% at 1kHz @ 0dBFS
• Digital Inputs
  • 2x Coax, up to 24bit 192kHz (stereo PCM)
  • 2x Optical, up to 24bit 192kHz (stereo PCM)
  • 1x USB Audio Class 2.0, ‘USB B’; up to 32 bit 192kHz (stereo PCM), DSD 256 (stereo DoP and native)
• Analogue Outputs
  • 1 pair line level RCA fix/var @ 2V RMS at 0dBFS
  • 1 pair line level XLR fix/var @ 4V RMS at 0dBFS
  • Output impedance: < 50 ohms
• General Information
  • Dimensions (WxHxD): 440 x 100 x 363mm
  • Main voltages: 230V/115V Internally set or 100V optional
  • Max. Consumption: 15W, <0.5W in standby
  • Weight: 6.8kg
