Το EVERsolo DAC-Z8 ειναι ψηφιοαναλογικος μετατροπεας PCM 32bit/768kHz, DSD 512 και MQA. Εισοδοι: 1x USB-B, 1x USB-C, 1x Optical, 1x Coaxial, Bluetooth receiver. Εξοδοι: 1x pair RCA, 1x pair XLR, 1x Headpphones.

Εγγυηση αντιπροσωπειας. Δυνατοτητα δοσεων.

Features

• DAC ES9038Pro XMOS XU316 Bluetooth 5.0 32bit 768kHz DSD512 MQA. EverSolo’s DAC-Z8 is a high-end DAC that is extremely powerful. It embeds high-end components with notably an ESS ES9038Pro digital/analog conversion chip and a XMOS XU316 USB interface allowing it to support high-resolution audio streams and to provide a clear and detailed sound reproduction. The DAC-Z8 also offers a wide range of features that make it a versatile and efficient device.
• ES9038Pro DAC. The heart of the DAC-Z8, its digital-to-analog conversion stage, is equipped with an excellent ESS ES9038Pro chip. This ensures low distortion and noise for a truly convincing high-fidelity music experience. In addition, the DAC-Z8’s audio circuitry is specifically calibrated to deliver its full potential.
• XMOS XU316 USB Interface. The USB input of the DAC-Z8 is combined with an XMOS XU316 interface, which is able to process audio data quickly and efficiently for optimal signal transmission. This chip also supports high-resolution streams up to PCM 32bit 768kHz and DSD512 Native, as well as MQA files.
• MQA Decoder. The EverSolo DAC-Z8 supports the decoding of MQA (Master Quality Authenticated) files from its USB, Toslink optical and coaxial inputs. This format allows to enjoy a sound quality as close as possible to the original studio recording.
• High precision clocks. The DAC-Z8 is equipped with two very high precision clocks on the frequencies 45.1584MHz and 49.152MHz. These allow you to enjoy a high quality decoding, ensuring a very low jitter for a detailed and precise sound..
• Optimized I/V circuit. The I/V circuit of the DAC-Z8 consists of 8 OPA1612 OPAs. It uses multi-channel signal shunting compensation technology, with the 8 OPAs corresponding to the 8 output channels of the I/V conversion stage, ultimately providing a two-channel parallel output. In addition to the high-precision resistors, this circuitry assists in the lossless amplification of the XLR, RCA and headphone outputs, improving channel separation, dynamic range and sonic integrity.
• Amplifier circuit & Balanced preamp output. The DAC-Z8’s analog audio circuitry is fully balanced. The XLR, RCA and headphone outputs are all processed by a balanced differential amplifier circuit for low noise and improved channel separation. The high-fidelity preamplifier circuitry provides precise and efficient volume control.
• Bluetooth 5.0. In addition to a complete connectivity, the DAC-Z8 has a Bluetooth 5.0 Qualcomm QCC5125 receiver, which allows you to broadcast your music remotely, from a smartphone or a tablet for example, while supporting the codecs of high-resolution transmission aptX HD and LDAC for a high quality restitution in wireless.
• Digital filters. The EverSolo DAC-Z8 offers no less than 7 PCM filters and 4 DSD filters. These allow you to adapt the sound reproduction of the device according to your listening preferences and your audio system.
• Low ripple power supply stage. A low-noise power supply stage and capacitor filter have been specifically designed for the DAC-Z8. They provide a clean, interference-free electrical signal to all of the unit’s audio circuits for rich, accurate sound reproduction.
• A powerful headphone amplifier. The DAC-Z8’s headphone amplifier also performs very well and is capable of providing comfortable power to accompany headphones with impedance from 16 to 300Ω without difficulty. This one also has a two-step gain control to accommodate both demanding headphones and more sensitive earphones.

Specifications

• Display Screen: 3-inch LCD Screen
• Chassis: Aviation aluminum alloy
• DAC: ES 9038Pro
• Audio Processor: XMOS XU316
• OPA Chip: OPA1612*10
• Power Supply: Low noise switching power supply
• Bluetooth Audio Input: Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC Bluetooth protocol
• USB-B DAC Input Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit and MQA
• USB-C DAC Input Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA
• Optical Audio Input Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
• Coaxial Audio Input Up to stereo PCM 192KHz 24Bit, DSD64 Dop and MQA
• Analog Audio Output Preamp output: XLR (balanced), RCA, Headphone amp output: 6.35mm single-ended
• USB Port: USB2.0 only for firmware upgrade
• Control Methods: Remote control, mobile APP control and knob control
• Headphone Impedance: 16-300Ω ?low gain mode:16-32Ω/high gain mode: 32-300Ω
• XLR Audio Characteristics
  • Output level(Vrms): 4.1Vrms@0dBFS
  • THD+N@A-wt: 0.000062%@1kHz-124dB@1kHz
  • THD+N@No-wt?0.000069%@1kHz-123dB@1kHz
  • Noise@No-wt: <1.2uVrms
  • SNR @No-wt: 133dB@1kHz
  • Frequency response: 20Hz-20kHz(±0.1dB)
  • Crosstalk: -130dB@1kHz
  • DNR @No-wt: 133dB@1kHz
• RCA Audio Characteristics
  • Output level (Vrms): 2.3Vrms@0dBFS
  • THD+N@A-wt: 0.000086% @ 1kHz(-121dB@1kHz)
  • THD+)@No-wt: 0.000097% @ 1kHz(-120dB@1kHz)
  • Noise @No-wt: <1.5uVrms
  • SNR @No-wt: 126dB @ 1kHz
  • Frequency response: 20Hz-20kHz (±0.1dB)
  • Crosstalk: -123dB @ 1kHz
  • DNR@No-wt: 126dB @ 1kHz
• Headphone (low gain mode)
  • Output level(Vrms): 1.2Vrms @ 0dBFS
  • Maximum undistorted power: 45 mW @ 32Ω
  • THD+N@A-wt: 0.00015%@1kHz(-116dB @ 1kHz)
  • THD+N@No-wt: 0.00018% @ 1kHz(-115dB @ 1kHz)
  • Noise @No-wt: <2uVrms
  • SNR@No-wt: 124dB @ 1kHz
  • Frequency response: 20Hz-20kHz (±0.1dB)
  • DNR @No-wt: 119dB @ 1kHz
• Headphone (high gain mode)
  • Output level(Vrms): 2.8Vrms @ 0dBFS
  • Maximum undistorted power: 26 mW @ 300Ω
  • THD+N@A-wt: 0.00016% @ 1kHz (-116dB@1kHz)
  • THD+N@No-wt: 0.00016% @ 1kHz (-116dB@1kHz)
  • Noise@No-wt: <2uVrms
  • SNR@No-wt: 124dB @ 1kHz
  • Frequency response): 20Hz-20kHz(±0.1dB)
  • DNR @No-wt: 124dB @ 1kHz
• Power Input: AC 110~240V 50/60Hz Max 0.35A
• Rated Power: 9W
• Dimensions: 270mm(W) * 187mm(D)* 50mm(H)
• Packing List: Remote control*1, power cable*1, USB cable*1, product manual*1
