Ο Rotel RB-1587 mkII ειναι τελικός ενισχυτής 7x155 WRMS/8Ω class AB.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Rotel’s RMB-1587MKII 7-channel amplifier furthers our heritage of producing high powered, high current, exceptionally manufactured Class AB amplifiers for multi-channel systems. The RMB-1587MKII delivers 7 channels of Class AB amplification at 155 Watts per channel into 8 ohms and drives 4 ohm speakers with over 250 Watts per channel, all channels driven.

Specifications

• Power Amplification
  • Continuous power output (8 Ω, 7 channels driven): 155 W / channel
  • Continuous power output (4 Ω, 7 channels driven): 250 W / channel
  • Continuous power output (4 Ω, 2 channels driven): 335 W / channel
• Audio Performance
  • Total harmonic distortion (20 Hz – 20 kHz): < 0.03%
  • Frequency response: 10 Hz – 100 kHz (+0 dB / −3 dB)
  • Signal-to-noise ratio (IHF “A” weighted): 111 dB
  • Gain: 26.6 dB
  • Intermodulation distortion (60 Hz : 7 kHz, 4:1): < 0.03%
  • Damping factor: 330
• Input Characteristics
  • Input sensitivity (RCA): 1.61 V
  • Input sensitivity (XLR): 3.4 V
  • Input impedance (RCA): 12 kΩ
  • Input impedance (XLR): 50 kΩ
• Power & Electrical
  • Power requirements: 230 V, 50 Hz
  • Power consumption: 1400 W
  • BTU rating (4 Ω, 1/8 power): 4016 BTU/h
• Dimensions & Weight
  • Dimensions (W × H × D): 43.1 × 23.7 × 45.6 cm
  • Front panel height: 5U / 22.1 cm
  • Net weight: 37.6 kg
