Το Yamaha TT-S303 ειναι belt drive πικαπ με ενσωματωμενο phono stage. Ενσυρματη διασυνδεσιμοτητα: RCA Out Phono/Line.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Enter a world of vinyl with the Yamaha TT-S303 turntable. The straight tonearm and rigid body deliver authentic sound from old and new vinyl collections.

Features

• Straight tonearm contributes to sound transparency and openness
• Belt-drive turntable
• Switchable Phono and Line output
• Authentic Hi-Fi design

Specifications

• Turntable Drive Method Belt drive
• Motor     DC motor
• Rotation Speed 33-1/3 rpm, 45 rpm
• Rotation Speed Variation ±2%
• Wow And Flutter 0.2%
• Platter Aluminium die-cast (Diameter 30 cm)
• Output Level 140 mV (-17 dBV, with RIAA EQ), 2.5 mV ± 3 dBV (without RIAA EQ, 1 kHz, 3.54 cm / sec)
• Signal To Noise Ratio 67 dB or higher (A-weighted, 20 kHz, LPF)
• Tonearm Static balance straight tonearm
• Effective Arm Length 223.5 mm
• Overhang 19 mm
• Stylus Pressure Adjustment Range 0-4 g
• Acceptable Cartridge Weght 15.5-19 g (including headshell)
• Attached Cartridge     Cartridge Type     MM type
• Output Voltage 2.5 mV (1 kHz, 3.54 cm / sec)
• Stylus Pressure 3.5 ± 0.5 g
• Cartridge Weight 5.0 ± 0.3 g
• Cartridge Height 17.0 ± 0.7 mm
• Head-shell Weight 10 g (including screws, nuts and wires)
• Audio Specifications Output Terminal     RCA: 1 (PHONO)
• General Power Consumption 1.5 W
• Standby Power Consumption 0.1 W
• Dimension (W×H×D) 450 x 136 x 368 mm
• Weight 4.8 kg
